6 Series M6 (S85) Coupe
Release banjo bolt (1) and detach pressure line (2) from vane
pump.
Installation:
Replace all sealing rings.
Make sure pressure line is laid without tension and with sufficient
spacing to adjoining components.
Tightening torque 32 41 3AZ
.
Release hose clamp (3) and detach suction line (4) from vane
pump.
Release screws (5) and remove vane pump towards front.
Tightening torque 32 41 1AZ
.
After installation:
•
Fill and bleed hydraulic system
•
Check pipe connections for leaks
RA Removing and installing/replacing vane pump for power steering (S85)
