6 Series M6 (S85) Coupe
37 15 055
Removing and installing/replacing EDC
control unit (M model)
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Remove trim for instrument panel, bottom left
•
Remove footwell side trim panel on A-pillar, right
Press floor trim at front right to one side.
Open cutout in insulating mat (shown with dotted line) and release
nut (1).
Disconnect plug connections (2).
Unscrew nut (3).
Slide control unit (4) with bracket upwards and remove sideways.
Replacement only:
Remove control unit (4) from bracket.
Replacement:
Carry out programming/coding.
RA Removing and installing/replacing EDC control unit (M model)
