6 Series M6 (S85) Coupe
Position counter-plate 41 1 092 at bottom on spring strut support
plate.
Position guide plate 41 1 091 at top on spring strut support plate
and secure.
Important!
Do not damage the spring support in the marked areas when
positioning the guide plate.
Note:
The illustration is a schematic representation and is to be applied
to the relevant vehicle type.
Insert punch numbers 41 0 000 (1) individually into guide
plate (2) and stamp vehicle identification number.
Note:
In the event of component or body replacement by the
workshops/garages, clearly delimit the vehicle identification
number at front and rear by stamping a "+" in place of the BMW
emblem.
Note national regulations.
RA Stamping vehicle identification number
