6 Series M6 (S85) Coupe
52 13 ...
Removing and installing/replacing trim for
release handle on left or right front seat
(normal/manual)
Remove release handle on left or right front seat,
refer to 52 14 033.
Unlock catches from outside by applying light pressure through
trim slot and remove trim from side.
Note:
On both sides on passenger seat.
Installation:
Catches (1) on trim must not be damaged.
RA Removing and installing/replacing trim for release handle on left or right front
BMW AG - TIS
19.01.2013 17:24
Issue status (12/2007) Valid only until next DVD is issued
