6 Series M6 (S85) Coupe
54 10 150
Removing and installing/replacing front
floating roofliner
Necessary preliminary tasks:
•
Remove glass tilt sunroof lid
Important!
Make sure that grease on the rails does not come into
contact with the floating roofliner.
Open roofliner (1) to such an extent that screws (2) are still
accessible.
Loosen screws (2).
Tightening torque 54 10 7AZ
.
Slide roofliner (1) uniformly towards front.
If necessary, raise slider (2) for roofliner.
Move slider (2) back until there is no longer any contact with the
roofliner.
RA Removing and installing/replacing front floating roofliner
