6 Series M6 (S85) Coupe
65 75 557
Removing and installing/replacing emergency
power siren with tilt sensor
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Remove rear right bumper bracket
Unscrew nut (1).
Remove emergency power siren cover (2) from bumper
bracket (3).
Disconnect plug connection (1).
Remove emergency power siren (2) in direction of arrow from
rear right bumper bracket (2).
RA Removing and installing/replacing emergency power siren with tilt sensor
BMW AG - TIS
19.01.2013 19:19
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
