6 Series M6 (S85) Coupe
66 20 508
Removing and installing (replacing) control
unit (Park Distance Control)
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Remove luggage compartment floor trim
Unclip electrical leads (1) from mounting for control units (2).
Pull control unit (3) slightly out of mounting for control units (2).
Unlock plug connections (4) and disconnect.
Remove control unit (3).
Replacement:
Carry out programming/coding.
RA Removing and installing (replacing) control unit (Park Distance Control)
