6 Series M6 (S85) Coupe
11 00 Engine in general S85
Cylinder
10
Bore
mm
92
Stroke
mm
75.2
Effective displacement
cm
3
4998
Compression ratio
:1
12
Max. permissible engine speed
rpm
8250
Compression pressure (of all cylinders roughly same
value)
bar
6.5-10
TD Engine in general S85
BMW AG - TIS
19.01.2013 20:12
Issue status (12/2007) Valid only until next DVD is issued
