Unlock plug on pulse generator of left and right exhaust camshafts and disconnect
Unlock plug on wiring harness section for alternator on cable duct and disconnect
Unlock plug on wiring harness section for A/C compressor on cable duct and
disconnect
Unlock plug on fuel injectors on left and right and disconnect
Unlock plug on electric switchover valve and disconnect
Unlock plug on Hall sensor on left and disconnect
Unlock plug on servomotor on left and disconnect
Unlock plug on coolant temperature sensor and disconnect
Unlock plug on idle speed actuator on left and right and disconnect
Unlock plug on tank venting valve on left and right and disconnect
Unlock control line on starter motor and disconnect
Unlock plug on Hall sensor on right and disconnect
Unlock plug on differential pressure sensor and disconnect.
Unlock plug of crankshaft pulse generator and disconnect.
Unlock plug on control sensor on left and right and disconnect
Unlock plug on monitor sensor on left and right and disconnect
Unlock plug on temperature sensor on left and right and disconnect
Release bracket on underside of transmission.
Lay cable, plugs of oxygen sensors, temperature sensor and
crankshaft sensor over bracket of right catalytic converter.
Feed out cable towards top.
Remove wiring harness.
Installation:
Pay attention to cable routing/mounting points.
Now clear the fault memory.
