6 Series E64 M6 (S85) CONVER
Installation:
Clean sealing surfaces (1). Note correct position of adapter
sleeves (2).
Note:
For a better overview, only a removed throttle valve assembly is
shown.
Installation:
Clean sealing surfaces on cylinder head.
Replace all O-rings (1) in cylinder head.
Note:
Perform basic throttle valve setting.
RA Removing and installing/sealing throttle valve assembly (S54)
