Universal transmission bracket
Special tools required:
•
00 2 030
•
23 0 132
•
23 4 050
Note:
-
The universal transmission bracket is introduced for the E60
AWD
-
Suitable for manual and automatic transmissions
Important!
Front and rear supports (1) can be laterally adjusted by
means of screws (2).
Carrier (3) of rear supports (1) can be longitudinally
adjusted by means of screw.
Supports must be adapted in length and width to the
transmission.
Supporting transmission:
Support transmission with special tools 23 4 050 , 23 0 132 ,
00 2 030 .
Important!
Transmission must be secured with tensioning strap (1).
RA Universal transmission bracket
