6 Series E64 M6 (S85) CONVER
31 35 007
Removing and installing/replacing holder for
left or right push rod/stabilizer
Remove front wheel.
Remove stabilizer link from holder (1).
Release screw (2).
Tightening torque 31 35 10AZ
.
Support swivel bearing with workshop jack and a suitable
mounting.
Unscrew nut (1).
Remove holder (2) for brake hose, pulse generator and if
necessary brake pad sensor.
Remove screw (4) with holder (3) towards front.
Installation:
Replace self-locking nut.
Tightening torque 31 31 3AZ
.
RA Removing and installing/replacing holder for left or right push rod/stabilizer
BMW AG - TIS
07.02.2013 04:33
Issue status (12/2007) Valid only until next DVD is issued
