6 Series E64 M6 (S85) CONVER
Backrest mounting on tunnel side:
1.
Install tunnel-side backrest strut.
Important!
Plastic bushing must not be damaged
2.
Tighten screw hand-tight.
Note:
Tighten down stud and screw only after mounting backrest on
both sides.
Tightening torque:
•
Stud on door side: 52 10 15AZ
.
•
Screw on tunnel side: 52 10 14AZ
.
If necessary, remove inertia reel unit.
RA Removing and installing/replacing backrest frame on front left or right seat (no
