6 Series E64 M6 (S85) CONVER
64 52 523
Replacing A/C system compressor (S85)
Warning!
Risk of injury!
Refrigerant circuit is under high pressure!
Follow safety instructions for handling R 134a refrigerant .
Follow safety instructions for handling refrigerant oil.
Avoid contact with refrigerant and refrigerant oil.
Important!
Risk of damage!
Restart engine only when A/C system has been correctly
filled.
Read and comply with notes on replacing compressor.
Follow instructions for opening and replacing parts in
refrigerant circuit.
If A/C system is opened for more than 24 hours:
Replacing drier insert for A/C system
Necessary preliminary tasks:
•
Drawing off, evacuating and filling the A/C system are not
included in the time value given for this work operation
•
Remove right intake filter housing
•
Remove A/C compressor drive belt
•
Remove front underbody protection
•
Remove stabilizer from front axle carrier
•
Remove right tension strut from front axle carrier
Release screws (1).
Disconnect pressure and suction lines.
Disconnect plug connection (2).
Installation:
Replace all sealing rings and moisten with refrigerant oil.
Tightening torque 64 52 1AZ
.
RA Replacing A/C system compressor (S85)
