6 Series E64 M6 (S85) CONVER
23 21 Transmission Shafts S 5 D 310 Z / MECH
Axial play (axial bearing clearance) of:
Output shaft
mm
0 ... 0.09
Output spigot
Radial runout
Max. mm
0.07
Output flange
Radial runout
Max. mm
0.07
Axial runout
Max. mm
0.1
