7 Series E38 730i (M60-1) SAL
34 00 Testing and bleeding brakes E38
Brake fluid: refer to Operating Fluids
Leak test with engine stopped: if applicable discharge
vacuum reservoir by operating brake pedal firmly about 10
times
Approx. force on pedal
approx. N
500
equals approx. line pressure
approx. bar
28...33
Max. pressure drop within 2 min.
%
8
Brake booster function test
(with engine running)
Approx. force on pedal
approx. N
200
Line pressure
bar
75 ... 90
