7 Series E38 730i (M60-1) SAL
64 50 A/C system, refrigerant amounts E38
Refrigerant filling quantity R 134a
Sourcing reference in Parts and Accessories Catalogue
The data on the nameplate in the engine compartment
are definitive
g
Up to 12/97
(large drier bottle):
1210
±
25
from 12/97
M52, M57, M62, M73:
680
±
10
M67: 700
±
25
from 12/97
M51:
1210
±
25
L7, w/out rear-comp. A/C system:
1270
±
25
L7, w/ rear-comp. A/C system:
1400
±
25
TD A/C system, refrigerant amounts E38
