7 Series E38 735iL (M62) SAL
11 31 015
Replacing right camshaft (M62 up to 9/98)
(Intake or exhaust side as applicable)
Cylinder bank 1-4
Unscrew and remove splash guard.
Remove both cylinder heads,
refer to 11 12 004.
Remove all spark plugs,
refer to 12 12 011.
Remove fan clutch with impeller,
refer to 11 52 020.
Removal
The removal of the camshaft is described separately from the
installation. Assembly sequence for removal and installation is
different.
Remove all oil lines to left and right cylinder head.
RA Replacing right camshaft (M62 up to 9/98)
