7 Series E38 735iL (M62) SAL
Unfasten grooved nut with special tool 24 4 110.
Installation:
Tightening Torque,
refer to Technical Data 24 13 1AZ.
Remove transmission extension from special tool.
Remove output flange from mounting.
Installation:
Coat sealing lip of radial seal and sealing surface of output
flange with transmission oil.
Lift out radial seal.
Installation:
Drive in radial seal flush using special tool 00 5 500 /
24 4 090.
RA Replacing radial seal for output flange (A5S 560Z)
BMW AG - TIS
08.02.2013 23:25
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 4 -
