7 Series E65 735i (N62) SAL

Page 2
background image

Release screws and remove sealing element (2). Remove
sensors (3 and 4).

Installation:

Replace sealing element (2).

Replace sealing rings on sensors (3 and 4).

Removing ignition coils.

Release both grounding cables.

Unlock and detach vent hose.

Unclip cable duct (1) and remove cable from holder.

Remove servomotor for right eccentric shaft.

RA  Removing and installing/sealing right cylinder head cover (N62/N62TU)

BMW AG - TIS

08.02.2013  02:34

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 2 -
