7 Series E65 735i (N62) SAL
Unscrew screws (1) and (2).
Important!
Bear in mind different bolt length (risk of damage):
-
Bolt (1), front: 8x30
-
Bolt (2), rear: 8x35
Installation:
Tightening torque: 21 Nm.
Unclip vacuum line from holder (1).
Remove screws (2) and (3).
Important!
Bear in mind different bolt length (risk of damage):
-
Bolt (2), front: 8x30
-
Bolt (3), rear: 8x35
Carefully lift out radial compressor (4).
Installation:
Replace both lower sealing rings on radial compressor.
Tightening torque: 21 Nm.
Important!
When reinstalling the radial compressor, make sure that both
adapter sleeves (1) are in place.
Modify following components when replacing the radial
compressor.
Release screws (1) and modify belt pulley (2) to new radial
compressor.
Installation:
Tighten screws crosswise.
Tightening torque: 9 Nm.
Important!
Make sure that spacer is fitted between radial compressor
and belt pulley.
