7 Series E65 735i (N62) SAL
Remove module carrier (1) with radiator and A/C condenser from
rubber mounts and push at bottom approx. 5 cm towards rear.
Installation:
Rubber mounts fall out easily, ensure correct installation position.
Release retaining clip (1) on left.
Release retaining clip (1) on right.
Release screw and remove power steering cooling loop (2)
towards bottom.
RA Removing and installing/replacing cooling loop for power steering
