7 Series E65 735i (N62) SAL
Mark severance cuts in accordance with specified measurements and cut.
Caution!
Cut outer metal sheet only.
Sunroof water drain hose is located behind severance cut a.
Measurement a = approx. 100 mm from roof edge.
Measurement b = approx. 70 mm behind bore dia. 6 mm.
Open weld joints in areas (1).
Note:
Side frame is bonded to floor pan in areas (3).
Installation information:
-
Apply window glass adhesive to cavity acoustic baffle (2).
-
Weld in reinforcing plates approx. 30 mm long at severance cuts.
RA Replacing rear left side panel (partial replacement, longitudinal member cover b
