7 Series E65 735i (N62) SAL
Important!
Bumper trim (1) is locked at sides in mounting holder and
must be unlocked for removal purposes (risk of damage).
Removing:
-
Insert special tool 00 9 317 at distance (A)
-
Disengage/unlock bumper trim (1)
-
Pull bumper trim (1) straight towards rear with aid of a 2nd
person
-
If necessary, disconnect plug connections
-
Pull off bumper trim (1)
A = 60 mm
Installation:
Observe gap dimensions.
RA Removing and installing rear bumper trim
BMW AG - TIS
08.02.2013 10:32
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 2 -
