7 Series E65 735i (N62) SAL
Note:
Secure coil spring (1) against springing out, e.g. with an
extension (2).
Unlock retaining hook (3) and gently pull out decorative trim (4).
Pull coil spring (1) with flat nose pliers (2) out of mount and
place over carrier (3) as illustrated.
Pull out decorative trim (4) in direction of arrow.
Installation:
Make sure coil spring (1) is correctly seated in mount.
RA Removing and installing / replacing decorative trims on centre console carrier s
