7 Series E65 735i (N62) SAL
65 77 750
Removing and installing (replacing) driver's
seat sensor
Warning!
Note airbag safety instructions!
Incorrect handling can activate airbag and cause injury.
Note:
To facilitate installation/removal of sensor, move seat upwards
fully.
Follow instructions for handling optical fibers.
Necessary preliminary tasks:
•
Disconnect and cover battery negative lead.
Unclip trim in upper rail at front (1) in direction of arrow and
remove.
RA Removing and installing (replacing) driver's seat sensor
