7 Series E65 735i (N62) SAL
Unlock driver's airbag.
Disconnect plug connection.
Remove airbag unit and connect adapter lead for firing airbag.
Warning!
Airbag unit must be fastened again to steering wheel after
adapter lead has been connected.
Do not damage adapter lead when doing so.
An airbag unit that is not fastened in accordance with
regulations can lead to injury when fired!
Connecting adapter lead to sensor, driver's/front passenger seat:
Operate seat in upwards direction.
Remove top rail trim at front.
Disconnect plug connections (1) from sensor (3) and connect
adapter lead 62 1 351 .
If necessary, mark strap with chalk at opening of B-pillar. In this
way, belt tension can be checked after firing.
Connecting adapter lead to sensor, front door, left and right:
Remove door trim.
Disconnect plug connection (1) from sensor (3).
Connect adapter lead 62 1 351 .
Warning!
Door trim must be screwed down again after adapter lead has
been connected.
Connecting adapter lead to A-pillar sensor, left and right:
RA Firing gas generators
