7 Series E65 745d (M67TU) SAL
11 28 010
Removing and installing / replacing alternator
drive belt (M67, M67TU)
Necessary preliminary tasks:
•
Remove fan clutch
Note:
If reusing the drive belt, mark the direction of rotation and
reinstall in the same direction.
Important!
Tensioning device is under spring pressure.
Press back tensioning roller (1) and thus remove drive
belt (2).
Installation:
Check drive belt for coolant and oil residue, clean, replace if
necessary.
Important!
The drive belt must be replaced if it is contaminated with
hydraulic fluid.
Check correct position of drive belt in grooves of drive gears.
RA Removing and installing / replacing alternator drive belt (M67, M67TU)
