7 Series E65 760i (N73) SAL
22 11 001
Replacing right engine mount (N73)
Necessary preliminary tasks:
•
Secure engine in installation position.
Release both engine mounts from above.
Tightening torque 22 11 2AZ
.
•
Remove both front wheels.
•
Lower front axle support.
Observe safety instructions on raising the vehicle.
Remove engine mount from mounting bracket.
Tightening torque 22 11 4AZ.
Installation:
Lug (1) of engine mount must point to middle of vehicle.
Engine mount designations:
Right engine mount:
Even component number
Left engine mount:
Odd component number
RA Replacing right engine mount (N73)
