04 · General

Airbag Modules

4 Tightening TorquesAirbag Modules

72 12 Airbag modules

Type

Thread

Tightening specification

Measure

1AZ Side airbag module

(door/door trim panel)

E65 / E66 /

E67

Nut

3.3 Nm

2AZ Passenger airbag module

(instrument panel)

E65 / E66 /

E67

8 Nm

3AZ Bracket of AHPS head airbag to

body

E65 / E66 /

E67

Metal screw

3.5 Nm

4AZ End fitting, AHPS head airbag, to

body

E65 / E66 /

E67

11 Nm

AZD Airbag modules

BMW AG - TIS

04.02.2013 09:27

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page - 1 -
