7 Series E66 730Ld (M57T2) SAL
25AZ Trailing arm to mount
M12x85
96 Nm
26AZ Rear apron to bracket
M8x25
26 Nm
27AZ Bracket to mounting bracket
M6x16
11 Nm
28AZ Rotary striker lock to cross strut
M8x35
18 Nm
29AZ Bearing pedestal to loading ramp
frame
M6x16
10 Nm
30AZ Outer towbar mount to longitudinal
member
M10x25
55 Nm
31AZ Mounting bracket to longitudinal
member
M10x25
78 Nm
32AZ Base plate to cross-member
M10x35
78 Nm
AZD Platform
