7 Series E66 735Li (N62) SAL
61 33 060
Removing and installing/replacing left fanfare
horn
Release screws (1).
Release screw (2) and remove cover (1).
Unlock plug connections (3) and disconnect.
Release nuts (2) and remove fanfare horn (1).
RA Removing and installing/replacing left fanfare horn
