8 Series E31 850CSi (S70) COUPE
11 00 Engine in General S70 B 56
Design
60
°
V
Cylinder
12
Bore
mm
86
Stroke
mm
80
Effective displacement
cm
3
5576
Compression ratio
:1
9.8
Power
kW at
rpm
280/5300
Max. top speed
rpm
6400
Max. torque
Nm at
rpm
550/4000
Compression pressure (approx. equal value for all
cylinders)
bar
11 - 13
