X Series E53 X5 3.0d (M57) OFFRD
11 66 000
Removing and installing or replacing vacuum
pump (M57)
Warning!
Scalding hazard!
Only perform these tasks on an engine that has cooled down.
E46 only:
Release screws on air duct (1).
Remove air duct (1).
Release screws (1).
Remove acoustic cover (2).
E39/E38 only:
Release screws (1).
Remove acoustic cover at front (2).
RA Removing and installing or replacing vacuum pump (M57)
BMW AG - TIS
03.02.2013 19:14
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
