X Series E70 X5 3.0d (M57T2) OFFRD
13 32 051
Replacing fuel filter (M57T2)
Necessary preliminary tasks:
•
Switch off ignition
•
Remove rear assembly underside protection
Recycling:
Catch and dispose of escaping fuel.
Observe country-specific waste-disposal regulations.
Release clamps (1).
Pull off hose.
Pull out retainer (2).
Detach fuel preheater (3) in direction of arrow.
Remove fuel filter.
Installation:
Modify retaining clamp.
Add final details to vehicle.
Installation:
Venting fuel system:
Vent fuel system with BMW diagnosis tester.
