X Series E70 X5 3.0d (M57T2) OFFRD
Release screw.
Slacken holder (1).
Tightening torque 17 11 10AZ
.
Release and disconnect coolant hoses (1).
Remove radiator (2) in direction of arrow.
Note:
Picture shows the E83! Under the right coolant hose is another
coolant hose which must be released and disconnected before the
radiator is removed.
RA Removing and installing radiator (M57T2)
