X Series E70 X5 3.0d (M57T2) OFFRD
34 11 220
Removing and installing/replacing both front
brake discs
Special tools required:
•
34 1 280
Necessary preliminary tasks:
•
Remove front wheels
•
Remove and clean brake pads
Note:
After completing work, read and comply with notes on braking in
new brake discs / brake pads.
Check minimum brake disc thickness:
-
Position special tool 34 1 280 at three measuring points in
area (1) and measure.
-
Compare measurement result and lowest value with setpoint
value.
Note:
New brake pads may only be installed if the brake disc thickness
is greater than or equal to the minimum brake disc thickness (MIN
TH).
If the brake discs are replaced, you must also fit new brake pads.
Brake discs may only be replaced in pairs (on each axle).
