X Series E70 X5 3.0d (M57T2) OFFRD
34 32 980
Replacing rear left or right brake hoses
Note:
Read and comply with General Information.
After completing work: Bleed braking system
Press clutch pedal down to floor and secure with pedal support.
Note:
The pedal support may only be released when the brake lines are
reconnected.
This prevents brake fluid from emerging from the expansion tank
and air from entering the system when the brake lines are opened.
Detach retaining clip (1) in direction of arrow.
Installation:
Retaining clip must be felt and heard to snap into place.
Important!
Grip brake hose at square head (3) to prevent connecting
piece from turning in retaining bracket.
Detach brake hose from brake line (2).
Installation:
Tightening torque 34 32 1AZ
.
Detach brake hose from brake caliper (1).
Installation:
Tightening torque 34 32 3AZ
.
RA Replacing rear left or right brake hoses
BMW AG - TIS
03.02.2013 22:39
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
