X Series E70 X5 3.0d (M57T2) OFFRD
52 26 000
Removing and installing/replacing left or right
rear seat (for 3rd seat row)
Right rear seat is removed in the same way as the left rear seat
depicted here.
Unclip cover (1) on left and right and remove in direction of
arrow.
Installation:
Replace faulty cover.
Release screws (1) on left and right.
Tightening torque 52 26 10AZ
.
Release screw (1).
Remove cover (2) in direction of arrow.
RA Removing and installing/replacing left or right rear seat (for 3rd seat row)
BMW AG - TIS
04.02.2013 03:47
Issue status (12/2007) Valid only until next DVD is issued
