X Series E70 X5 3.0d (M57T2) OFFRD
61 35 107
Removing and installing/replacing Junction
Box electronics
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Disconnect battery negative lead
•
Remove trim for instrument panel, bottom left
Release screws (1).
Remove air duct (2).
Release screw (1).
Slacken wiring harness in cable holder (2).
RA Removing and installing/replacing Junction Box electronics
BMW AG - TIS
04.02.2013 05:36
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
