X Series E70 X5 3.0d (M57T2) OFFRD
65 77 016
Removing and installing/replacing airbag
control unit
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Warning!
Note airbag safety instructions!
Incorrect handling can activate airbag and cause injury.
Necessary preliminary tasks:
•
Disconnect battery negative lead and cover
•
Remove complete centre console
•
Remove rear cabin ventilation duct
Unscrew nuts (1).
Tightening torque 65 77 1AZ
.
Disconnect plug connections (2).
Installation:
Make sure ground cable (2) is correctly laid.
If necessary, replace damaged cable shoe on ground cable (2).
RA Removing and installing/replacing airbag control unit
