X Series E70 X5 3.0d (M57T2) OFFRD
67 62 000
Removing and installing/replacing flat motor
for front left or right power window unit
Necessary preliminary tasks:
•
Remove sound insulation in front doors
•
Remove front section of power window unit
Release screws (1) and detach flat motor (2) from power
window unit.
Installation:
Retaining pins (3) must not be released!
Important!
To ensure tension-free installation of flat motor, observe the
specified screwing sequence without fail.
Tighten first screw (1), then screw (2) and finally screw (3).
Tightening torque 67 62 1AZ
.
After installation:
A normalization must be carried out in order to activate anti-
trapping protection.
Normalization sequence:
•
Ensure adequate system voltage
•
All doors closed
•
Press correspond power window switch in "Close" position
and hold for approx. 2 seconds with window closed
Note:
RA Removing and installing/replacing flat motor for front left or right power windo
