X Series E70 X5 3.0d (M57T2) OFFRD
72 12 000
Removing and installing/replacing airbag
module on passenger side
Warning!
Read and comply with safety regulations for handling airbag
modules and pyrotechnical belt tensioners.
Incorrect handling can activate airbag and cause injury.
Necessary preliminary tasks:
•
Disconnect battery negative lead
•
Remove instrument panel trim
Unclip airbag lead with holders (1) from instrument panel.
Unscrew nuts (1).
Installation:
Replace nuts.
Tightening torque 72 12 01AZ
.
Remove airbag module from instrument panel.
RA Removing and installing/replacing airbag module on passenger side
BMW AG - TIS
04.02.2013 08:33
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
