X Series E70 X5 3.0Si (N52K) OFFRD
24 14 002
Replacing shaft seal for selector shaft
(GA6HP19Z)
Special tools required:
•
24 5 361
•
24 5 362
•
24 5 364
•
24 5 366
Important!
After completion of work, check transmission fluid level.
Use only the approved transmission fluid.
Failure to comply with this requirement will result in serious
damage to the automatic transmission!
Necessary preliminary tasks:
-
Remove underbody protection
Unfasten nut.
Remove cable (1).
Installation:
Adjusting cable:
-
Release nut
-
Adjust cable by means of holder (2)
Distance A
≥
1 mm.
