X Series E70 X5 3.0Si (N52K) OFFRD
34 11 000
Removing and installing/replacing brake pads
on both front disc brakes (1 piston)
Special tools required:
•
34 1 050
•
34 1 080
•
34 1 280
Important!
The brake pad wear sensor must be replaced once it has
been removed (brake pad wear sensor loses its retention
capability in the brake pad).
Necessary preliminary tasks:
•
Remove front wheels
•
Remove brake pad wear sensor
Lever out retaining spring (1) in direction of arrow towards rear.
Installation:
Attach retaining spring (1) first at top and bottom on brake caliper
and then allow to engage in recesses of brake caliper housing.
RA Removing and installing/replacing brake pads on both front disc brakes (1 piston
