X Series E70 X5 3.0Si (N52K) OFFRD
84 10 050
Removing and installing (replacing) USB hub
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Necessary preliminary tasks:
•
Remove gear selector switch carrier
Unlock catch (1) and guide USB hub (2) in direction of arrow out
of holder (3).
Disconnect plug connection (4).
Installation:
Make sure USB hub (2) is correctly seated in holder (3).
Make sure wiring harness is correctly laid.
RA Removing and installing (replacing) USB hub
BMW AG - TIS
07.02.2013 05:54
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
