X Series E70 X5 4.8i (N62TU) OFFRD
Insert special tool 16 1 080 into filler neck.
Special tool 16 1 080 has two different diameters for
petrol/gasoline and diesel vehicles!
Slide extraction hose of extractor unit, refer to BMW Service
Workshop Equipment and Planning Documentation, through
special tool 16 1 080 into the fuel filler pipe, turning in the
process if necessary.
Insertion length approx. 170 cm.
Draw off fuel with suction unit (refer to BMW Service Workshop
Equipment) as far as possible.
Follow drawing off of fuel on fuel gauge in instrument cluster.
Drawing off residual fuel quantity:
Drawing off residual fuel amount is not included in the time value
of this operation.
Important!
Ensure car interior is adequately ventilated.
Catch dripping fuel in a suitable container.
Remove left sensor unit.
Remove right sensor unit.
Draw off residual fuel quantity through service openings.
Fuel filling:
Insert special tool 16 1 080 into filler neck.
Special tool 16 1 080 has two different diameters for
petrol/gasoline and diesel vehicles!
Slide extraction hose of extractor unit, refer to BMW Service
Workshop Equipment and Planning Documentation,
approx. 40 cm into fuel filler pipe.
Fill fuel from suction extractor unit.
Extracting fuel after a defect in the suction jet pump or fuel
pump:
Draw off right half of tank completely through fuel filler pipe.
Remove left sensor unit.
Insert extraction hose through service opening in tank, fuel (also
residual quantity) can be drawn off.
