X Series E70 X5 4.8i (N62TU) OFFRD

Page 2
background image

Undo oil filler plug (1).

Pour in gear oil up to lower edge of opening for oil filler plug (1).

Tightening torque  27 00 11AZ

.

Replace sealing ring.

RA  Replenishing / changing transfer case oil (ATC 700)

BMW AG - TIS

08.02.2013  02:20

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 2 -
