X Series E70 X5 4.8i (N62TU) OFFRD
33 41 151
Replacing left or right wheel bearing on rear
axle shaft
Important!
Do not damage multipole impulse ring.
Necessary preliminary tasks:
•
Remove drive flange for rear axle shaft
Release screws.
Remove wheel bearing.
Installation:
Stick in screws again / replace.
Tightening torque 33 41 2AZ
.
Installation:
Keep contact surface (2) of wheel bearing/wheel carrier clean
and free from oil and grease.
Except when replacing: Recondition tapped holes (1).
Install new wheel bearing.
RA Replacing left or right wheel bearing on rear axle shaft
BMW AG - TIS
08.02.2013 04:38
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
