X Series E70 X5 4.8i (N62TU) OFFRD
37 11 010
Removing and installing/replacing front active
stabilizer
Warning!
Danger of poisoning if oil is ingested/absorbed through the
skin!
Risk of injury if oil comes into contact with eyes and skin!
Important!
Adhere to the utmost cleanliness. Do not allow any dirt to
enter the hydraulic system.
Close off pipe connections with plugs.
Note:
A film of grease on the anti-friction bearing in no way impairs the
operational capability of the stabilizer.
In a warranty case you must always provide a fault memory
printout, even where there is no fault memory entry, with the
defective part.
Necessary preliminary tasks:
•
Remove front wheels
•
Remove front underbody protection
•
Remove front right wheel arch cover (front section)
•
Remove radiator air duct
•
Remove both brake air ducts with holder
•
Remove fan cowl
•
Remove heat exchanger from front axle carrier and tie up
•
Remove both stabilizer links from stabilizer
RA Removing and installing/replacing front active stabilizer
